Electro-mechanical single point lubricator

Weight

0.62 kg

capacity [ml]

250

colour

amber

country of origin

Portugal

feature

electro-mechanical single point automatic lubricator

grease

LGWA 2

max. feed line length [m]

norm

DIN 51825: KP2N-30

protection class

IP65

thread

G 1/4

type

electro-mechanical single point lubricator

used with

LGWA 2/SD125, LGWA 2/SD250

Details Attributes Variants (1) Substitutes (2)

TLSD 125/WA2 SKF

Electro-mechanical single point lubricator

The SKF SYSTEM 24 TLSD 250/WA2 is an electro-mechanical single point automatic lubricator. It is filled with 250 ml of SKF LGWA 2 grease for wide temperature ranges and extreme pressure. It is recommended for electric motors, conveyors, fans and pumps.Key benefits of using an automatic lubricator are improved employee safety, increased machine reliability and optimized maintenance operations.

Flexible dispense rate from 1 to 12 months
Maximum discharge pressure of 5 bar over the whole dispensing period
Lubricator's status visible with red/yellow/green LED
Compact size permits installation in restrictive areas
Supplied with support flange for enhanced sturdiness
Suitable for both direct and remote installation

manufacturer	SKF
dimensions	0 x 0 x 0
Weight	0.62 kg
feature	electro-mechanical single point automatic lubricator
thread	G 1/4
colour	amber
norm	DIN 51825: KP2N-30
capacity [ml]	250
grease	LGWA 2
type	electro-mechanical single point lubricator
used with	LGWA 2/SD125, LGWA 2/SD250
working description	Electro mechanical
protection class	IP65
max. feed line length [m]	3
country of origin	Portugal
